LLPG508 (2x 5G/LTE, 2x WiFi 6E, GNSS)
GNSS Multiband Surface Mount Antenna
5 cables: two Global 5G Sub-6 Cellular LTE, two WiFi 6E, one GNSS
Cable 1 & 2: 617-960 MHz, 3 dBi & 1710-6000 MHz, 4 dBi
Cable 3 & 4: 2.4-2.5 & 4.9-7.2 GHz, 5 dBi
Cable 5 (GNSS): 1561, 1575, & 1602 MHz, LNA 26 dB, 5 dBi
Specify LLP508 for GPS only models.
Description
The 5-cable LLPG508 (2x 5G/LTE, 2x WiFi 6E, GNSS) antennas include two Global 5G LTE antennas, two WiFi 6E antennas and one GNSS antenna. This provides MIMO (multiple-input-multiple-output) coverage for both Cellular and WiFi. In addition, GNSS operates on GPS, Galileo, Glonass, QZSS or Beidou at 1561, 1575, & 1602 MHz.
The Global LTE 5G-ready antenna element covers: 617-960 & 1710-6000 MHz. Furthermore, it covers all Cellular bands, worldwide. In the US, this includes the new CBRS (Citizens Broadband Radio Service) at 3.55-3.7 GHz and Band 71 at 617-698 MHz.
Measuring 9” ( 22.8cm ) x 3.5” ( 8.9cm ) with low profile height of 1.25” ( 3.18cm ), the LLPG508 (2x 5G/LTE, 2x WiFi 6E, GNSS) offers a far more compact and discreet antenna than many of its counterparts.
To customize antenna configurations, visit our eStore.
Read more about our other antennas in the LLP Series
