YAG12-5500

YAG12-5500 (10/12 dBi 4.4–6.0 GHz)

10/12 dBi Wideband Directional Antenna

The YAG12-5500 delivers 10 or 12 dBi directional gain across separated 4.4–5.4 and 5.47–6.0 GHz ranges.

  • Provides 10 dBi gain from 4.4–5.4 GHz and 12 dBi from 5.47–6.0 GHz.
  • Supports WiFi, public-safety 4.9 GHz, DSRC 5.9 GHz, and military 4.4 GHz applications.
  • Adjusts up to 45° vertically and horizontally on the standard wall mount.
  • Offers SMA or N-plug configurations with a one-foot low-loss cable.
BUY ONLINE
REQUEST A QUOTE

Customization: Cable type, cable length, and connectors can be configured for specific installation requirements.

Product Description

The YAG12-5500 covers several high-band fixed-wireless uses without treating its two operating ranges as continuous. It provides 10 dBi gain from 4.4–5.4 GHz and 12 dBi from 5.47–6.0 GHz for compatible point-to-point, mesh, WiFi, DSRC, public-safety, and military radios.

The slim ASA enclosure measures 6.35 inches long and extends to 7.5 inches with the wall bracket. Its two-axis swivel allows 45° adjustment for link alignment, and an optional pipe mount supports outdoor mast installations.

Ideal applications:

  • High-band point-to-point links
  • WiFi, DSRC, public-safety, and military radios

Example Model Configurations: YAG12-5500-3C-WHT-12, YAG12-5500-3X-WHT-12

Key Specifications

Feature Specification
Technology Wi-Fi / WLAN; DSRC; public-safety fixed wireless; military fixed wireless
Frequency

Wideband fixed wireless: 4.4-5.4 GHz ; 5.47-6.0 GHz
Gain

Wideband fixed wireless: 10 dBi at 4.4-5.4 GHz ; 12 dBi at 5.47-6.0 GHz
Connector / Cable

Wideband fixed wireless connector: SMA plug or N plug; other connectors available

Wideband fixed wireless cable: low-loss 195

Wideband fixed wireless length: 1 ft (30.5 cm)
Mounting Standard two-axis swivel wall mount; optional YAG-PMK swivel pipe mount; adjustment up to 45° vertically and horizontally.
Dimensions Radome: 2.75 in H x 6.35 in L x 0.56 in W; with mount: 2.75 × 7.5 × 0.56 in
Material ASA
Maximum Input Power

Wideband fixed wireless: 25 W maximum
Environmental Rating / Qualifications

Ingress: IPX5

Qualifications: EN 300 019-2-4; IEC 60068
Operating Temperature -40 to 85 °C

Models & Configurations

Model / Configuration Configuration Details
YAG12-5500-3C-WHT-12 4.4-5.4 GHz; 5.47-6 GHz; Wall mount; White; Cable: LL-195; SMA Plug; Cable length: 1 foot
YAG12-5500-3X-WHT-12 Pole / pipe; White; Cable: LL-195; N Plug

Tech Documents & Resources

yag12-5500-spec-sheet

File size: 284.56 KB
Created: 11-06-2020
Updated: 11-06-2020
Hits: 1875
Download Preview

YAG12-5500 Radiation Pattern

File size: 516.70 KB
Created: 26-05-2020
Updated: 26-05-2020
Hits: 1685
Download Preview
