MXFG708, MXFG702

MXFG702 (2× LTE, 4× Wi-Fi, GNSS)

7-in-1 LTE, 4×4 WiFi and GNSS MaxFin Antenna

The MXFG702 supports 2×2 LTE, four WiFi paths and active GNSS for vehicle platforms with a four-chain local network radio.

  • Provides four dual-band WiFi feeds for 4×4 radios.
  • Supports two LTE paths and active GNSS.
  • Consolidates seven connections in the narrow MaxFin housing.
BUY ONLINE
REQUEST A QUOTE

Customization: Cable type, cable length, and connectors can be configured for specific installation requirements.

Product Description

The MXFG702 is the seven-feed MaxFin configuration for systems that combine a four-chain WiFi radio with 2×2 LTE and GNSS. The shared housing keeps the full radio set on one through-hole vehicle mount.

Four WiFi paths: Each WiFi element covers 2.4–2.5 GHz and 4.9–6.0 GHz, supporting 4×4 operation.

Cellular and position coverage: Two LTE feeds span 694–960 MHz and 1710–3700 MHz, while active GNSS handles the primary global positioning constellations.

Example Model Configurations: MXFG702-3C3C3C3C3C3C2C-BLK-180, MXFG702-3C3C3J3J3J3J2C-BLK-180

Key Specifications

Feature Specification
Technology LTE, Wi-Fi, GPS, GLONASS, Galileo
Frequency

Cellular: 694-960 MHz; 1710-3700 MHz

Wi-Fi: 2400-2500 MHz; 5000-6000 MHz

GNSS: 1575 MHz; 1602 MHz
Gain

Cellular: 0-3 dBi at 694-960 MHz; 4 dBi at 1710-3700 MHz

Wi-Fi: 4 dBi at 2.4-2.5 GHz; 5 dBi at 5-6 GHz

GNSS: 5 dBi; 26 dB LNA
Configuration 2 × cellular; 4 × Wi-Fi; 1 × GNSS
MIMO

Cellular: 2×2 MIMO-capable

Wi-Fi: 4×4 MIMO-capable
GNSS Bias 3.3/5 VDC; 20 mA max, 10 mA typical
Connector / Cable

Connectors: Cellular: 2 x SMA plug (male); Wi-Fi: 4 x reverse-polarity SMA plug (male); GNSS: 1 x SMA plug (male)

Cable: Cellular / Wi-Fi: LL-195; GNSS: RG-174

Length: All RF groups: 15 ft (4.5 m)
Mounting Stud feedthrough mount; magnetic-mount variant is documented for the family; Ground-plane dependent; 1 sq ft ground plane recommended
Dimensions 7.50 in L x 2.25 in W x 2.50 in H (190×57×64 mm); magnetic-mount height 2.95 in (75 mm)
Material

Housing: ASA UV-stable / UV-inhibitive plastic
Environmental Rating / Qualifications

Ingress: IP69K stud mount; IP67 magnetic mount, when properly mounted

Qualifications: IEEE 1478; EN 61373; MIL-STD-810G; TIA-329.2-C shock and vibration
Operating Temperature −40°C to +80°C

Models & Configurations

Model / Configuration Configuration Details
MXFG702-3C3C3C3C3C3C2C-BLK-180 GLONASS/GPS; 7 cables; Black; Cable: LL-195; RG-174; SMA Plug; Cable length: 15 ft
MXFG702-3C3C3J3J3J3J2C-BLK-180 4 x Wi-Fi; Black; Cable: LL-195; RG-174; SMA Plug; Rev Pol SMA Plug; Cable length: 15 ft

Tech Documents & Resources

MXF702-Spec-Sheet_198

File size: 636.04 KB
Created: 10-06-2020
Updated: 29-08-2025
Hits: 2247
Download Preview
