    Antenna Solutions for Medical

    The hospitals of the future will rely on IoMT & IoHT for Quality Connected Healthcare.

  • Medical Antenna Solutions for Connected HealthCare, IoMT, IoHT, Medical IoT antennas

    Antenna Solutions for Medical

Medical IoT Antenna Solutions

As wireless options for Medicine have expanded, and security protocols developed to protect privacy, wireless communication for Medical IoT has become an increasingly important part of the way data is handled for Connected Healthcare.  Recently these types of data transmissions have fallen under the heading IoMT, the Internet of Medical Things or IoHT, the Internet of Health Things. See Our Medical IoT Antenna Solutions Flyer.

Multiple wireless protocols are used for Medical IoT:

  • Cellular, both broadband (5G-ready, Sub-6, 600-6000 MHz) & narrowband (NB-IoT)
  • WiFi, including single-band 2.4 GHz applications, dual-band 2.4 & 5 GHz & the new WiFi 6e band up to 7.2 GHz
  • RFID, tracking the location of the devices themselves or contents removals from storage areas
  • ISM, and other low power wireless networks (LPWAN) such LoRaWAN® & Sigfox
  • Land Mobile Radio, traditional 2-way communications on VHF or UHF

Mobile Mark offers a wide range of antennas across all wireless protocols and in multiple configurations and forms.  With our Engineering Technical Center, we also offer the engineering expertise and guidance to help you optimize your network or device.  If you require an antenna solution that is not immediately available from our long list of options, we will work with you to modify an existing antenna or custom design an entirely new antenna solution.

Compact Antennas

CVL-2400/5500 Compact Over Molded Dual Band WiFi Medical IoT Antenna

CVL-2400/5500

Over Molded Dual Band
WiFi 2.4 – 2.5 GHz &
4.9 – 6.0 GHz bands
2.41” L, .65” W, & .08” Deep

PSKN4-W6E-RS ( MU-MIMO, WiFi 6E ) Tri-band

PSKN4-W6E-RS

WiFi 6E Rubber Duck
Straight or 90° Swivel
2.4-2.5 GHz &
5.15-7.125 GHz

EM-LTE Medical IoT, Embedded, Compact Antenna, IoHT, IoMT, Connected HealthCare, Digital Health, IoT

EM-LTE

Flexible LTE Internal Strip
Fits in Tight Spaces
695-960 MHz
& 1710-2700 MHz

EM-900/2400 Dual Feed Embedded Flexible Antenna for LORWAN® & Sigfox

EM-900/2400

Dual Feed Embedded Flexible Antenna
863-928 MHz & 2.4-2.5 GHz
LORWAN® & Sigfox

Mobile Antennas

LPD-LVHF VHF Mobile High Impact Low Profile Surface Mount

LPD-LHF

VHF Mobile Surface Mount
145-161 MHz, 2 dBi Gain
High Impact with a Low Profile of 3.25” Tall

LTMWG944 (4x Sub-6 5G Cellular, Up to 4x WiFi & GNSS) for Medical IoT, IoHT, IoMT, Connected Health

LTMWG944

Up to 9-Connections
4x LTE, 1-4x WiFi & GNSS
Sub-6 & 5G Ready,
617 – 6000 MHz

LLPG708 Low Profile Mobile Medical IoT Antenna, 5G Ready, Cellular, WiFi, GNSS

LLPG708

Low Profile Design
2x LTE, 1-4x WiFi & GNSS
Sub-6 & 5G Ready,
617 – 6000 MHz

NXD-W, 4 WiFi, Low Profile, MIMO WiFi, Antenna, Dual-Band WiFi, Medical IoT, IoMT, IoHT, Connected Healthcare, Digital Health

NXD-W

Low Profile MIMO WiFi
Up to 4x Dual-Band WiFi
Ground Plane Independent
3.52” Dia. & 0.625” H

Infrastructure Antennas

XW-24/5XO-FPS-711, Luxul, Flat Panel, Dual Band WiFi, Antenna, Circular Polarization, Medical IoT, Connected HealthCare, Digital Health, Infrastructure, IoMT, IoHT

XW-24/5XO-FPS-711

Flat Panel Dual Band WiFi
Circular Polarization
Prevents Multipath Interference

SCR-2400/5500, Dual Band, WiFi, Corner Reflector, Antenna, Half-wave, Medical IoT, IoHT, IoMT, Connected Health, Digital Health

SCR-2400/5500

Dual Band WiFi Corner Reflector
Point-to-Point Coverage
Half-Wave Element

CLTM603, 6x WiFi, Medical IoT, IoHT, Connected Health, IoMT, Ceiling Mount, Antenna, MIMO WiFi, LTM, Infrastructure

CLTM603

Ceiling-Mount Antenna
6x WiFi MIMO
2.4 – 2.5 & 4.9 – 6.0 GHz
4 dBi Gain

PN6-868, PN6-868N

PN6-915

RFID Reader Antenna
Right or Left Hand Circularly Polarized
902-928 MHz, 6 dBic Gain

FOUR Antenna Solutions Categories for IoMT

Mobile Mark Medical IoT Device Antenna Solutions

DEVICE ANTENNA SOLUTIONS FOR CONNECTED HEALTHCARE

There are two categories for antenna device solutions: internal mounted & external mounted antennas.

Mobile Mark offers a number of printed circuit board antennas that can be mounted inside the device. Two important factors when an antenna is mounted inside a device:

  • The device itself be made from a material, such as plastic or fiberglass, that will not block the signal.
  • The antenna designer needs to ensure internal or embedded, antenna is mounted in a location that will provide the best connectivity.

Some devices will have a connector port built into the side of the device and an external antenna can be connected directly to that port.  Other external antennas are stud mounted through a hole in the device. Custom-shaped antennas fit on narrow NEMA style boxes, are also available.

Medical IoT Mobile Antenna Solutions

MOBILE MEDICAL IOT ANTENNA SOLUTIONS

Vehicle-mounted antennas are typically divided into two categories: Single-band antennas, for a dedicated application and Multi-band antennas, used when multiple applications are combined into one antenna

Emergency vehicles and ambulances are examples of medical vehicles that need to stay connected to the larger wireless network for both fleet management applications and to convey urgent and critical information. VHF and UHF have traditionally been used for emergency response vehicles.

Examples of multi-band applications are:

  • Emergency vehicles or medical transport vehicles
  • Large mobile scanner equipment housed in trailers or vans and moved from hospital to hospital
  • Temporary medical facilities

The multi-band wireless feature offers the ability to track the equipment, monitor onboard vehicle telematics, and communicate critical medical information. These antennas typically cover Cellular, WiFi, and GNSS, frequency bands. The multi-band antennas are paired with routers, gateways, or modems and might require two Cellular connections for a single Cellular Carrier and others might require four Cellular connections to provide for Dual Carrier MIMO (multiple-input-multiple-output).

Medical IoT Infrastructure Antenna

INFRASTRUCTURE ANTENNA SOLUTIONS FOR DIGITAL HEALTH

Wireless communications is needed throughout a hospital setting both within a building and between buildings. Mobile Mark offers infrastructure equipment that helps maintain the critical connections for Medical IoT.  Infrastructure is typically divided into two categories:

  • Omni-directional antennas, such as Fiberglass Base Station antennas
  • Directional antennas, such as Yagi, Log-periodic, and Panel antennas

Just as the infrastructure antennas extended wireless coverage outside the buildings, well-placed in-building antennas can extend the coverage to all corners within the building.

Mounting options for Interior Mounted antennas are often divided into:

  • Ceiling Mounts
  • Wall Mounts

Well-placed in-building antennas can extend the coverage to all corners within the building. Also, Mobile Mark custom designs antennas covering WiFi 6e to provide the very latest in WiFi performance.

WiFi 6e represents a major advancement in WiFi coverage.  The IEEE802.11ax standards allow for wider bandwidth and faster data processing. The FCC recently released the 6.125-7.125 GHz band to be used for WiFi6e.  Mobile Mark’s WiFi6e antennas also cover the 5.850-5.895 GHz band which was repurposed by the FCC for unlicensed commercial uses such as WiFi.  WiFi 6e routers can operate on all unlicensed bands from 2.4-2.5 GHz & 5.15-7.125 GHz.

Medical IoT Special Antenna Applications

SPECIALIZED ANTENNA SOLUTIONS FOR MEDICAL IOT

While Cellular and WiFi are the most common wireless technologies used by the Medical community.  There are many times when the unlicensed 915 MHz band in the US and the 868 MHz band in Europe will be used.  There is a reason this band is often called “ISM” which stands for Industrial, Scientific, and Medical!  LoRaWAN® and Sigfox, two low-power wide-area network (LPWAN) technologies that also make sure of these bands.  It is not necessary for users of these bands to have a license. In addition, RFID is another application that falls in this band.

Wireless applications in the medical community will continue to evolve.  Mobile Mark can help you prepare for the next generation of wireless activities.
